K5TRA Station
Weak signal operation from 6M through 2304 MHz and 10 GHz. Shown are two IC-820H transceivers. One is used for 144 MHz and 432 MHz. The other is used as IF radio for 902 MHz and 1296 MHz transverters. Six meter operation (and HF) is provided by an Elecraft K3. The IF radio for the 222 MHz and the 10 GHz transverters is a Yaesu FT2000. All of these transverters have been designed and built from scratch by K5TRA. The latest addition to the station is 2304 MHz. That transverter is a Kuhne (DB6NT) MKU23G2 with a 144 MHz IF. You may also find the link to my "Antenna Farm" interesting.
